H.E.A Lions Head Solar Package 8 kW Plus hybrid inverter, a 10.89 kW DC PV array and 16 kWh of lithium storage (No Installation)
R 187,995.00
Skip to product information
H.E.A Lions Head Solar Package 8 kW Plus hybrid inverter, a 10.89 kW DC PV array and 16 kWh of lithium storage (No Installation)
R 187,995.00
Lions Head Package
Lions Head is a powerful mid‑range hybrid solar system that balances strong daytime generation with substantial battery backup for busy households. Built around an Solis S6 8 kW Plus hybrid inverter, a 10.89 kW DC PV array (18 × JA Solar 605 W bifacial panels) and approximately 16 kWh of lithium storage (H.E.A 16/13 51.2v Residential battery), this package is engineered to deliver extended backup during load‑shedding, reliable daily cycling, and professional installer‑grade safety and protection.
| Quantity | Description |
| 1 | PV on Roof and Hazard Labels Pack |
| 5 | 35mm2 single-core 1000V HV DC cable 1m - Black |
| 2 | 4mm2 single-core PV DC cable 50m - Red |
| 3 | Flat Twin + Earth 6mm2 10m 3C |
| 5 | 35mm2 single-core 1000V HV DC cable 1m - Red |
| 1 | GP Housewire 10mm2 20m Black |
| 1 | PROJOY 63A Single Phase Change Over Switch |
| 1 | GP Housewire 4mm2 50m Green/Yellow Earth wire |
| 1 | GP Housewire 4mm2 50m Green/Yellow Earth wire |
| 1 | GP Housewire 10mm2 20m Green/Yellow wire |
| 1 | GP Housewire 6mm2 20m Red |
| 1 | GP Housewire 6mm2 20m Black |
| 1 | GP Housewire 10mm2 20m Red |
| 1 | 25mm white 10m contractor pack c/w 10 glands |
| 18 | JA Solar 605W n-type Bifacial Double Glass Half-Cell MBB Traceable LB MC4 |
| 1 | Dektite Lead Multicable Solar Flashing (Tiled or Slate) |
| 2 | 600V Protection Box 2 Inputs 2 Outputs 16A MCB Type II SPD |
| 1.5 | Hubble Lithium AM-5 5.12kWh 51.2V Battery (Pack of 2) |
| 1 | KETO 1 Battery Disconnector with 250A Fuses |
| 1 | Hager 50A MCB 6kA C curve 2P |
| 1 | Hager 32A MCB 6kA C curve 2P |
| 1 | Hager 63A MCB 6kA C curve 2P |
| 1 | Hager 24-way DB IP65 Surface Mount |
| 1 | Hager 63A RCD 30mA 4P Earth Leakage |
| 1 | Hager 40kA 275Vac 1ph+N 2P T2 SPD |
| 1 | Hager Green+Red LED indicator light 230V DIN |
| 3 | Scame Electrical Solutions 4 MOD. DIN Blank Strips for DB |
| 1 | EZI-TIE UV resistant cable ties 200x4.8mm - 100-pack |
| 8 | 35mm2 by M8 Ring Terminal Lug |
| 1 | Solis Warranty Ext. of 5 years (Total 10y) for S6 Pro 6kW Hybrid |
| 6 | End Clamp+ 30 - 50mm Silver |
| 16 | Middle Clamp+ 30 - 50mm Silver |
| 2 | Wood screw slated tiles countersunk 6 x 80, pack of 100 |
| 54 | Roof hook UK Plain tiles/slates (without wood screw) |
| 9 | VarioSole + End Cap 50X37 rail - RIGHT/LEFT Grey (1 pair) |
| 9 | VarioSole+ Rail connector for rail 50 x 37 mm. |
| 9 | VarioSole+ Mounting Rail 50 x 37 x 3300mm |
| 10 | MC4-Evo2A 1500V DC Connector Double Pack 0316/0317 (Kit 2) |
| 1 | K&N Single Phase AC Switch Disconnector 40A |
| 1 | 3m CAN BMS cable for Solis with Hubble Lithium batteries |
| 1 | S6 8kW Plus Single Phase Low Voltage Hybrid Inverter with 10 Year Warranty |
| 2 | 100x100mm White PVC Trunking, 3m length |
| 3 | 50x50mm White PVC Trunking, 3m length |
| 1 | Delivery |
